Endress Hauser E&H Flow Meter Dissolved Oxygen Transmitter Liquisys COM223-DX0005
| Place of Origin | Germany |
|---|---|
| Brand Name | Endress Hauser |
| Certification | CSA Gen. Purpose |
| Model Number | COM223-DX0005 |
| Minimum Order Quantity | 1 piece |
| Price | negotiable |
| Packaging Details | standard carton packing |
| Delivery Time | on request |
| Payment Terms | T/T |
| Supply Ability | 100pcs per month |
Contact me for free samples and coupons.
WhatsAPP:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Application | Water, Waste Water, Process | Material | Panel Housing |
|---|---|---|---|
| Dimension | 96mm X 96mm X 146mm(built In Depth) 3.74x3.74x5.61inch( Built In Depth) | Ingress Protection | IP65 |
| Input | 1-channel Transmitter | Output / Communication | 0/4-20mA, Hart, Profibus. |
| Measuring Principle | Amperometric Oxygen Measurement | Design | Dissolved Oxygen Transmitter In A Panel Housing. |
| Highlight | Endress Hauser e&h flow meter,Dissolved oxygen transmitter IP65,Liquisys COM223 DX0005 |
||
Product Description
Endress Hauser Dissolved oxygen transmitter Liquisys COM223-DX0005
Field of application
Liquisys COM223 is a standard transmitter for use with COS41 and COS61 oxygen sensors. It improves your operational safety thanks to continuous plausibility, process and sensor checks. Select from numerous hardware and software modules, such as relays or fieldbus communication, to adapt it exactly to your measuring task. This modularity also allows you to upgrade the transmitter at any time. A simple menu and calibration make configuration and operation fast and easy.
The Liquisys COM223 transmitter works with Oxymax COS41 and Oxymax COS61 dissolved oxygen sensors in environmental applications, such as:
- O2 control in the aeration basin
- O2 control and monitoring of drinking water
- Surface water monitoring
- Process water treatment and monitoring
- O2 control in fish farming for optimum growth conditions
Liquisys COM223 features the following protocols and interfaces:
- 0/4...20 mA
- HART
- PROFIBUS DP
- PROFIBUS PA
SPECIFICATIONS
Measuring principle: Amperometric oxygen measurement
Application:Water, waste water, process
Characteristic:4-wire transmitter with a two-line display
Design:Dissolved oxygen transmitter in a panel housing.
Material:Panel housing
Dimension:96mm x 96mm x 146mm(built in depth);3.74x3.74x5.61inch( built in depth)
Process temperature:Display and current output
Ingress protection:IP65
Input:1-channel transmitter
Output / communication:0/4-20mA, Hart, Profibus.Modbus RS485, Modbus TCP, Ethernet
Additional certifications:CSA Gen. Purpose
