ATEX Endress Hauser Instruments Ultrasonic Measurement Time-Of-Flight Prosonic FDU91-RG2AA
Product Details:
| Place of Origin: | Germany |
| Brand Name: | Endress+Hauser |
| Certification: | ATEX, FM, CSA, IEC Ex, INMETRO, NEPSI, EAC Ex |
| Model Number: | FDU91-RG2AA |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 piece |
|---|---|
| Price: | negotiable |
| Packaging Details: | standard carton packing |
| Delivery Time: | on request |
| Payment Terms: | T/T |
| Supply Ability: | 100pcs per month |
|
Detail Information |
|||
| Supply / Communication: | 4-wire (HART, Profibus DP) | Ambient Temperature: | -40 °C ... 80 °C (-40 °F ... 176 °F) |
|---|---|---|---|
| Measuring Principle: | Ultrasonic | Characteristic / Application: | Separated Version With Field Housing Or Top Hat Rail Housing For Control Cabinet Instrumentation, 300 M In-between Sensor And Transmitter |
| Max. Measurement Distance: | Liquids: 10 M (33 Ft), Solids: 5 M (16 Ft) | Accuracy: | +/- 2 Mm + 0.17% Of Measured Distance |
| Process Temperature: | -40 °C ... 80 °C (-40 °F ... 176 °F) | Main Wetted Parts: | PVDF (fully Welded IP68 / NEMA6P) |
| Highlight: | ATEX Endress Hauser Instruments,FM Endress Hauser Instruments,FDU91-RG2AA |
||
Product Description
Endress Hauser Ultrasonic measurement Time-of-Flight Prosonic FDU91-RG2AA
SPECIFICATIONS
Measuring principle:Ultrasonic
Characteristic / Application:Separated version with field housing or top hat rail housing for control cabinet instrumentation, 300 m in-between sensor and transmitter
Supply / Communication:4-wire (HART, Profibus DP)
Accuracy:+/- 2 mm + 0.17% of measured distance
Ambient temperature:-40 °C ... 80 °C(-40 °F ... 176 °F)
Process temperature:-40 °C ... 80 °C(-40 °F ... 176 °F)
Process pressure / max. overpressure limit:0.7 bar ... 4 bar abs(10 psi ... 58 psi)
Main wetted parts:PVDF (fully welded IP68 / NEMA6P)
Process connection:G / NPT 1"
Blocking distance:0.3 m (1 ft)
Max. measurement distance:Liquids: 10 m (33 ft),Solids: 5 m (16 ft)
Communication:Transmitter:4 ... 20 mA HART Profibus DP
Certificates / Approvals:ATEX, FM, CSA, IEC Ex, INMETRO, NEPSI, EAC Ex
Options:Second 4...20 mA output；
Components:Transmitter:FMU90, FMU95
Application limits:Foam / high turbulence possible:FDU92；Flange-flush assembly:；FDU91F；For tank farms scanner:；FMU95
Field of application
The FDU91 ultrasonic sensor for continuous, non-contact and maintenance-free level measurement of fluids, pastes, sludges and powdery to coarse bulk materials. But also for flow measurement in open channels and measuring weirs. The measurement is unaffected by dielectric constant, density or humidity and also unaffected by build-up due to the self-cleaning effect of sensors. Suited for explosion hazardous areas. Maximum measuring range in liquids 10m (33ft), solids 5m (16ft).
Sensor for continuous, non-contact level measurement of fluids and of bulk materials in silos, on belts, stockpiles and in crushers. Also for flow measurement in open channels and at weirs. Typically used in measurements in low structural heights.
-
Process connection: Thread
-
Temperature: -40 to +80°C (-40 to +176°F)
-
Pressure: +0.7 to +4bar (+10 to +58psi)
-
Maximum measuring range: Liquids 10m (33ft), solids 5m (16ft)
-
Blocking distance: 0.3m (1ft)
-
International explosion protection certificates
Benefits
-
Integrated temperature sensor for Time-of-Flight correction. Accurate measurements are possible, even if temperature changes are present
-
Hermetically welded PVDF sensor for highest chemical resistance
-
Suited for rough ambient conditions thanks to separate installation from the transmitter
(up to 300m) -
Reduced build-up formation because of the self-cleaning effect
-
Integrated automatic sensor detection for transmitters FMU90/FMU95 for simple commissioning
-
Weather resistant and flood-proof (IP 68)
-
Integrated heating against a build-up of ice at the sensor (optional) ensures reliable measurement
