Industrial Grade KFD2-EB2 Power Feed Module 20 x 119 x 115 mm 0.8 x 4.7 x 4.5 inch W x H x D with Lightweight Design

Basic Information
Place of Origin: SINGAPORE
Brand Name: P+F
Certification: CE
Model Number: KFD2-EB2
Document: 189783_eng.pdf
Minimum Order Quantity: 1pc
Packaging Details: standard carton packing
Delivery Time: on request
Payment Terms: T/T
Supply Ability: 100pcs per month
Connection: Terminals 11+, 12- Terminals 8+, 9- Rated Voltage: 20 ... 30 V DC
Display Elements: LEDs Control Elements: DIP Switch
Mass: Approx. 100 G Dimensions: 20 X 119 X 115 Mm (0.8 X 4.7 X 4.5 Inch) (W X H X D) , Housing Type B2
Highlight:

Lightweight Design Power Feed Module

,

Industrial Grade Power Feed Module

,

KFD2-EB2 Power Feed Module

P+F Power Feed Module KFD2-EB2

The power feed module supplies the Power Rail with a voltage of 24 V DC and a maximum current of 4 A. In the event of a device fault or a wiring fault of any isolator on the Power Rail, the collective error messaging relay alerts the controller via a binary I/O point. This relay can be configured as normally-open or normally-closed. A green LED on the front of the device indicates the power state, and a red LED lights up during a fault condition. In the sense of functional safety (SIL) the device provides no dangerous failures. Thereby the safe condition of the supplied isolators must be defined as the de-energized state. Thus the device will not influence the safety calculation or the SIL value. This device is compatible with all versions of the Power Rail.


Technical Data


Supply

Connection

terminals 11+, 12-
terminals 8+, 9-

Rated voltage

20 ... 30 V DC
The maximum rated operating voltage of the devices plugged onto the Power Rail must not be exceeded.

Fusing

5 AT/250 V AC
recommended maximum utilization of the fuse: 80 %

Power dissipation

≤ 1 W

Output

Connection

Power Rail

Output current

max. 4 A

Output voltage

Ui ≥ rated voltage Ur = Ui - 0.6 V

Fault signal

relay output: NO contact

Contact loading

30 V AC/ 2 A / cos φ ≥ 0.7 ; 40 V DC/ 2 A

Energized/De-energized delay

approx. 20 ms / approx. 20 ms

Indicators/settings

Display elements

LEDs

Control elements

DIP switch

Configuration

via DIP switches

Labeling

space for labeling at the front

Directive conformity

Electromagnetic compatibility



Directive 2014/30/EU

EN 61326-1:2013 (industrial locations)

Conformity

Electromagnetic compatibility

NE 21:2017

Degree of protection

IEC 60529:2001

Ambient conditions

Ambient temperature

-40 ... 70 °C (-40 ... 158 °F)

Mechanical specifications

Degree of protection

IP20

Connection

screw terminals

Mass

approx. 100 g

Dimensions

20 x 119 x 115 mm (0.8 x 4.7 x 4.5 inch) (W x H x D) , housing type B2

Mounting

on 35 mm DIN mounting rail acc. to EN 60715:2001

Data for application in connection with hazardous areas

Certificate

UL 22 ATEX 2853 X


Marking

Industrial Grade KFD2-EB2 Power Feed Module 20 x 119 x 115 mm 0.8 x 4.7 x 4.5 inch W x H x D with Lightweight Design 0 II 3G Ex ec nC IIC T4 Gc

Directive conformity



Directive 2014/34/EU

EN IEC 60079-0:2018+AC:2020 , EN IEC 60079-7:2015+A1:2018 , EN IEC 60079-15:2019

International approvals

FM approval

FM 22 US 0031 X


Control drawing

116-0160

UL approval

E106378

CSA approval

CoC 1051840

IECEx approval



IECEx certificate

IECEx UL 16.0051X


IECEx marking

Ex ec nC IIC T4 Gc


Industrial Grade KFD2-EB2 Power Feed Module 20 x 119 x 115 mm 0.8 x 4.7 x 4.5 inch W x H x D with Lightweight Design 1
